Engine Kohler KD 625/2 Expand

Kohler Engine KD 625 Diesel

Kohler Kohler

ED4C0380

New

The Kohler KD 625 engine is an air-cooled engine with the following features:

  • kW (HP) 18.8 (25.5) @3000
  • Air-cooled engine
  • Four strokes
  • 2 cylinders in line
  • Compatible with KD625 spare parts and 9LD Lombardini spare parts
  • 3-year manufacturer's warranty

More details

Available

€6.092,45 tax incl.

€5.035,08 tax excl.

Caja Transporte Asvarta

Envío internacional gratuito*

Free shipping worldwide.
*See conditions

Distribuidores Oficiales Kohler y Lombardini

Kohler and Lombardini official distributors

KOHLER KD 625 engine

Characteristics:

  • New robust design for the most extreme conditions
  • Equipped with a larger air filtration cartridge with higher capacity
  • Cyclone separator with one-way valve for dust discharge
  • New integrated sound absorber provides reduced noise levels
  • Owner's Manual

Our air cooled diesel engines are designed with state-of-the-art air filters to increase durability and lengthen service intervals. If you combine all these with the cast iron cylinder liners of the engine, you get a machine that doesn't know how to stop.

Engine type
Four-stroke, integral air-cooling fan, independent aluminium alloy head, electric starter, direct injection

Recommended uses:

Fruit/vineyard tractors - Water pump (irrigation) - Concrete sprayer - Mini dumper - Vibrating plate - Self-priming water pump - Air compressor - Generator - Cooling units - Engine welder - Engine sweeper - Aerial platform - High pressure washer - Fire pump

Lenght633
Height599
Width557
Height115
Displacement (cc)1248
Cooling SystemAir-Cooled
Cylinders2
FuelDiesel
Power18.8 (25.5) @3000
Number of cylinders2
Bore and stroke (mm)

95 x 88

Displacement (cm3)

1248

Aspiration

Naturally aspirated

Cycle4 stroke
Combustion system

Direct injection

Rotation

Counter-clockwise (view from main PTO side)

Cooling system

Air

Fuel tank capacity (l)

Options available 7, 10, 12

Oil sump capacity (l)

2.8

Lenght (mm)

633

Width (mm)

557

Height (mm)

599

Dry weight (kg)

115

Max. power kW (hp) @rpm

18.8 (25.5) @3000

Maximum Torque (Nm@rpm)

67.0@2000

Emission Compliance

Stage V
