Generating Set XP K9 Alize Kohler SDMO

Generating Set XP K9 Alize Kohler SDMO

Range INDUSTRIAL: Leading edge technology, designed for regular, intensive use, that is powerful and quiet.

Advantages SDMO XP K9 Alize

• Entire group guaranteed 3 years
• KOHLER water-cooled industrial engine
• Complete control panel
• Low noise level
• Large Autonomy

Add-ons included with XP K9 Alize

• User and maintenance manual

Several supported uses:

• Ideal for small vehicles
• For cultivators
• Agriculture
• Do-it-yourself
• Construction
• Industrial purposes

Find more SDMO generators in our SDMO Spain catalogue to find the alternative you are looking for.

ENGINE SPECIFICATIONS

• Engine brand: KOHLER KDI
• Engine ref.: KDW1003
• Air inlet system: Athmo
• Cylinders configuration: L
• Number of cylinders: 3
• Displacement (L): 1,03
• Bore (mm): 75
• Stroke (mm): 77,60
• Compression ratio: 22,8 : 1
• Speed (RPM): 1500
• Pistons speed (m/s): 3,88
• Maximum stand-by power at rated RPM (kW): 8,50
• Frequency regulation, steady state (%): +/- 2.5%
• Governor type: Mechanical
• Consumption @ 75% PRP load (L/h) *: 1,90
• Oil system capacity including filters (L): 2,40
• Oil consumption 100% ESP 50Hz (L/h): 0,04

ALTERNATOR SPECIFICATIONS

• Alternator commercial brand: KOHLER
• Alternator ref.: KH00260T
• Voltage regulation at established rating (+/- %): 1

SHIPPING IN SPAIN AND PORTUGAL

IBERIAN PENINSULA (SPAIN AND PORTUGAL)

Shipping cost: 7,50 €

Balearics, Ceuta and Melilla

Shipping cost: 9,50 €

Canary Islands

Shipping rates to the Canary Islands depend on the weight of the package:

Shipping to European Union

*Zone 1: Germany, Belgium, Denmark, Slovakia, France, Ireland, Italy, Luxembourg, Netherlands, Poland, Sweden

**Zone 2: Austria, Croatia, Estonia, Finland, Latvia, Lithuania, Czech Republic

**Zone 3: Bulgaria, Cyprus, Slovenia, Hungary, Malta, Romania

Shipments to Europe to non-European Union Countries (*1)

Shipping to África (*2)

Shipping to Asia y Oceanía (*3)

Shipping to North América (*4)

Shipping to Central, South America and Islands (*5)

Shipping to Nordic Islands (*6)

(*1) No EU: Norway, United Kingdom, Switzerland, Albania, Belarus, Bosnia and Herzegovina, Macedonia, Moldova, Montenegro, Serbia, Ukraine, Turkey, Gibraltar, Vatican City, Liechtenstein, Monaco, San Marino, Guernsey, Jersey,

(*2) Africa: Morocco, Equatorial Guinea, Algeria, Egypt, South Africa, Chad, Gambia, Central African Republic, Tunisia, Yemen, Sudan, Angola, Benin, Botswana, British Indian Ocean Territory, Burkina Faso, Burundi, Cape Verde, Cameroon, Democratic Republic of Congo, Republic of Congo, Ivory Coast, Djibouti, Eritrea, Ethiopia, Gabon, Ghana, Guinea-Bissau, Kenya, Lesotho, Liberia, Madagascar, Malawi, Mali, Mauritius, Mauritania, Mozambique, Namibia, Niger, Nigeria, Reunion Island, Rwanda, Sao Tome and Principe, Senegal, Seychelles, Sierra Leone, Swaziland, Tanzania, Togo, Uganda, Zambia, Zimbabwe, Comoros, Mayotte, Somalia, Libya

(*3) Asia + Oceanía: Israel, Bangladesh, Bhutan, Burma, Brunei, Nepal, Sri Lanka, Armenia, Azerbaijan, Georgia, Kazakhstan, Kyrgyzstan, Turkmenistan, Uzbekistan, Singapore, Thailand, Taiwan, Mongolia, Hong Kong, Philippines, Indonesia, Malaysia, Japan, South Korea, India, Saudi Arabia, Bahrain, United Arab Emirates, Jordan, Kuwait, Lebanon, Oman, Pakistan, Qatar, China, Laos, Macau, East Timor, Vietnam, Afghanistan, North Korea, Palestinian Territories, Iraq, Tajikistan, Cambodia, Iran, Russia, Australia, Norfolk Island, New Zealand, Cook Islands, Fiji, Guam, Northern Mariana Islands, Kiribati, Marshall Islands, Micronesia, New Caledonia, Palau, Papua New Guinea, French Polynesia, Solomon Islands, Samoa, American Samoa, Tuvalu, Vanuatu, Wallis and Futuna, Maldives, Tonga, Nauru, Niue, French Southern Territories.

(*4) North America: USA, Mexico, Canada, Saint Pierre and Miquelon

(*5) Central + South America + Islands: Puerto Rico, Belize, Costa Rica, El Salvador, Guatemala, Haiti, Honduras, Nicaragua, Dominican Republic, Chile, Argentina, Brazil, Bolivia, Panama, Paraguay, Peru, Uruguay, Venezuela, Colombia, Ecuador, Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bermuda, Dominica, Grenada, Guadeloupe, Guyana, Virgin Islands, Jamaica, Martinique, Montserrat, Saint Martin, Saint Vincent and the Grenadines, Saint Lucia, Trinidad and Tobago, Netherlands Antilles, South Georgia and the South Sandwich Islands, Maldives, Saint Barthelemy, Turks and Caicos Islands, Cayman Islands, Saint Kitts and Nevis, US Virgin Islands, Cuba, French Guiana, Suriname.

(*6) Nordic Islands: Iceland, Greenland, Faroe Islands.

Length (mm): 1410

Width (mm): 720

Height (mm): 1080

Deposit (L): 50

Net weight (kg): 530

Lubrication system

• Oil capacity (l) 8.70
• Min. oil pressure (bar) 1.50
• Max. oil pressure (bar) 10
• Oil sump capacity (l) 8,50
• Oil consumption 100% ESP 50Hz (l/h) 0.01

Air intake system

• Max. inlet back pressure (mm H2O) 150
• Combustion air flow rate (l/s) 18.70
• Heat expelled in the exhaust (kW) 13
• Exhaust gas temperature (°C) 520
• Exhaust gas flow (l/s) 59

Exhaust system

• Max. exhaust back pressure (mm H2O) 500

Cooling system

• Engine and radiator capacity (l) 6.80
• Fan power (kW) 0.50
• Fan air flow rate (m3/s) 0.65
• Radiator back pressure (mm H2O)
• Type of cooling Glycol-Ethylene
• Radiated heat (kW) 4
• Heat expelled in the water HT (kW) 17
• Engine stop water temperature (°C) 110

General

• Engine brand KOHLER KDI
• Engine part number KDI1903M *
• Athmo Suction Type
• Cylinder arrangement L
• Number of cylinders 3
• Displacement (l) 1.86
• Diameter (mm) * Stroke (mm) 88 * 102
• Compression ratio 18.5 : 1
• Speed (tr/mn) 1500
• Max. auxiliary power at nominal speed (kW) 19
• Frequency regulation (%) +/- 2.5%
• Injection type Indirect
• Type of control Mechanical
• Air Filter Type, Dry Models

Alternator specifications

• KOHLER alternator trademark
• Ref. Alternator KH00630T
• Number of poles 4
• Number of bearings
• Ring and brushless technology
• IP23 protection rating
• Insulation class H
• Number of wires 12
• Ability to maintain a short circuit at 3 In for 10 s Yes
• AVR Adjustment Yes
• Direct Coupling

Application data

• Excess speed (rpm) 2250
• Power factor (Cos Phi) 1
• Voltage regulation at the set speed (+/- %) 1
• Waveform: NEMA=TIF <45
• Waveform: IEC=FHT <2
• Total harmonic distortion at no load DHT (%) 3,3
• Total harmonic distortion on DHT load (%) 2,1
• Response time (Delta U = 20% transient) (ms) 200
