K12M Industrial Kohler SDMO Diesel Generator

K12M SDMO Generator

These premium quality SDMO generators or generator sets offer endless application possibilities, covering a wide range of uses to perfectly adapt to any application, use and use.

The POWER PRODUCTS series of Kohler SDMO is committed to an optimal energy response to all needs and situations that require an electrical power between 7.2 and 4200kVA.

This generator comes equipped with the following premises:

• Optimized height that allows the use of the generator by means of fork displacement.
• Optimized against corrosion, through studies carried out by the French Institute of Corrosion.
• Optimized soundproofing.
• Separate 9dB(a) silencer.
• DC starter battery charged with electrolyte.
• Instruction manual.
• Packaging covered with plastic film.
• It is delivered with oil and antifreeze liquid.
• A water-cooled industrial diesel engine .
• Charging alternator and electric starter.
• Standard air filter.
• Schneider or ABB electrical circuit breaker, adapted to short-circuit currents in generator sets.
• Welded steel chassis that absorbs 85% of vibrations.
• Up to four lift points on the chassis.
• Steel chassis with double layer of epoxy paint.

The generators and engines were tested in their prototype and production phase, built in the factory. This design ensures a minimum of 1000 hours of salt spray resistance. With ergonomic accesses that allow maintenance and a very simple connection of the generator set. In addition to a robust design optimized for transport and usability.

Please note that all these generators are manufactured in France in the modern and certified facilities of Kohler SDMO.

Standard characteristics of alternators

• All models are brushless rotary field alternators
• Comply with NEMA MG1, IEEE and ANSI standards for temperature rise and engine commissioning
• AVR voltage regulator offers increased short-circuit capability
• Self-ventilated and voltage drop-proof construction
• Better voltage waveform

Industrial Generator K12M

This equipment is totally versatile and compact, it can also be used in automatic or manual mode. Offering the following features:

• Certified and optimized sound levels Monitoring.
• Sustained power, even in extreme conditions
• Optimized fuel consumption
• Compact size
• Improved power quality and high starting and charging capacity, according to ISO 8528-5
• Rugged chassis and high-quality covers
• Protection of installations and persons
• Approved by the highest standards

This marine generator set is guaranteed for 3 years, like the rest of the generator sets and generators of the brand.

K12M Silent Generator Set

Thanks to its design, this generator has a robust chassis and high quality covers that guarantee the safety of people and the use of the facilities. Approved by the highest standards. Its engine is composed of the highest levels of demand, offering a high power density, starting capacity with a high autonomy and a low temperature always maintained. With a wide maintenance interval offered.

This K12M marine generator offers certified and optimized sound levels that allow its usability to be superior for the user and their type of application. Thanks to its optimized fuel consumption, this generator is prepared to deliver sustained power even in extreme conditions. With the highest quality of electricity and high start and load, according to ISO 8528-5 standard.

The cooling of this generator becomes a flexible solution thanks to the electrically driven radiator that composes. It allows a production capacity at high temperatures and altitudes thanks to the optimization applied by Kohler SDMO.

GENERAL SPECIFICATIONS

• Engine brand KOHLER KDI
• KOHLER alternator trademark
• Voltage (V) 230 single phase
• APM303 control panel
• Optional Box APM403
• Optional Box M80
• Terminal strip 5 - 5
• Type of cooling Radiator
• Performance class G2

DIMENSIONS COMPACT VERSION

• Length (mm) 1410
• Width (mm) 720
• Height (mm) 1020
• Tank capacity (L) 50
• Net weight (kg) 440

DIMENSIONS SOUNDPROOFED VERSION M126

• Soundproofing type M126
• Length (mm) 1750
• Width (mm) 775
• Height (mm) 1230
• Tank capacity (L) 50
• Net weight (kg) 610
• Sound pressure level @1m in dB(A) 50Hz (75% PRP) 67
• Sound pressure level @7m in dB(A) 54

Exhaust system

• Exhaust gas temperature (°C) 460
• Exhaust gas flow (l/s) 46
• Max. exhaust back pressure (mm H2O) 500

Cooling system

• Engine and radiator capacity (l) 5.80
• Fan power (kW) 0.90
• Fan air flow rate (m3/s) 0.85
• Radiator back pressure (mm H2O)
• Type of cooling Glycol-Ethylen

Application data

• Excess speed (rpm) 2250
• Power factor (Cos Phi) 1
• Voltage regulation at the set speed (+/- %) 1
• Waveform: NEMA=TIF <45
• Waveform: IEC=FHT <2
• Total harmonic distortion at no load DHT (%) 3,6
• Total harmonic distortion at DHT load (%) 2,0
• Response time (Delta U = 20% transient) (ms) 200
• Performance data Rated continuous power 40°C (kVA) 13.50
• Maximum unbalance rate (%) 100
• Peak motor start (kVA) based on x % voltage drop with a power factor of 0.3

SHIPPING IN SPAIN AND PORTUGAL

IBERIAN PENINSULA (SPAIN AND PORTUGAL)

Shipping cost: 4,50 €

FREE shipping on purchases over: 35 €

Ceuta and Melilla

Shipping cost: 7,50 €

FREE shipping on purchases over: 50 €

Canary Islands

Shipping rates to the Canary Islands depend on the weight of the package:

Shipping to European Union

*Zone 1: Germany, Belgium, Denmark, Slovakia, France, Ireland, Italy, Luxembourg, Netherlands, Poland, Sweden

**Zone 2: Austria, Croatia, Estonia, Finland, Latvia, Lithuania, Czech Republic

**Zone 3: Bulgaria, Cyprus, Slovenia, Hungary, Malta, Romania

Shipments to Europe to non-European Union Countries (*1)

Shipping to África (*2)

Shipping to Asia y Oceanía (*3)

Shipping to North América (*4)

Shipping to Central, South America and Islands (*5)

Shipping to Nordic Islands (*6)

(*1) No EU: Norway, United Kingdom, Switzerland, Albania, Belarus, Bosnia and Herzegovina, Macedonia, Moldova, Montenegro, Serbia, Ukraine, Turkey, Gibraltar, Vatican City, Liechtenstein, Monaco, San Marino, Guernsey, Jersey,

(*2) Africa: Morocco, Equatorial Guinea, Algeria, Egypt, South Africa, Chad, Gambia, Central African Republic, Tunisia, Yemen, Sudan, Angola, Benin, Botswana, British Indian Ocean Territory, Burkina Faso, Burundi, Cape Verde, Cameroon, Democratic Republic of Congo, Republic of Congo, Ivory Coast, Djibouti, Eritrea, Ethiopia, Gabon, Ghana, Guinea-Bissau, Kenya, Lesotho, Liberia, Madagascar, Malawi, Mali, Mauritius, Mauritania, Mozambique, Namibia, Niger, Nigeria, Reunion Island, Rwanda, Sao Tome and Principe, Senegal, Seychelles, Sierra Leone, Swaziland, Tanzania, Togo, Uganda, Zambia, Zimbabwe, Comoros, Mayotte, Somalia, Libya

(*3) Asia + Oceanía: Israel, Bangladesh, Bhutan, Burma, Brunei, Nepal, Sri Lanka, Armenia, Azerbaijan, Georgia, Kazakhstan, Kyrgyzstan, Turkmenistan, Uzbekistan, Singapore, Thailand, Taiwan, Mongolia, Hong Kong, Philippines, Indonesia, Malaysia, Japan, South Korea, India, Saudi Arabia, Bahrain, United Arab Emirates, Jordan, Kuwait, Lebanon, Oman, Pakistan, Qatar, China, Laos, Macau, East Timor, Vietnam, Afghanistan, North Korea, Palestinian Territories, Iraq, Tajikistan, Cambodia, Iran, Russia, Australia, Norfolk Island, New Zealand, Cook Islands, Fiji, Guam, Northern Mariana Islands, Kiribati, Marshall Islands, Micronesia, New Caledonia, Palau, Papua New Guinea, French Polynesia, Solomon Islands, Samoa, American Samoa, Tuvalu, Vanuatu, Wallis and Futuna, Maldives, Tonga, Nauru, Niue, French Southern Territories.

(*4) North America: USA, Mexico, Canada, Saint Pierre and Miquelon

(*5) Central + South America + Islands: Puerto Rico, Belize, Costa Rica, El Salvador, Guatemala, Haiti, Honduras, Nicaragua, Dominican Republic, Chile, Argentina, Brazil, Bolivia, Panama, Paraguay, Peru, Uruguay, Venezuela, Colombia, Ecuador, Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bermuda, Dominica, Grenada, Guadeloupe, Guyana, Virgin Islands, Jamaica, Martinique, Montserrat, Saint Martin, Saint Vincent and the Grenadines, Saint Lucia, Trinidad and Tobago, Netherlands Antilles, South Georgia and the South Sandwich Islands, Maldives, Saint Barthelemy, Turks and Caicos Islands, Cayman Islands, Saint Kitts and Nevis, US Virgin Islands, Cuba, French Guiana, Suriname.

(*6) Nordic Islands: Iceland, Greenland, Faroe Islands.

GENERAL SPECIFICATIONS

• Engine brand MITSUBISHI
• KOHLER alternator trademark
• Voltage (V) 400/230
• Control panel APM303
• Optional Box APM403
• Optional Box M80
• Optional box Terminal strip

• Type of cooling Radiator
• Class of performance G1

DIMENSIONS COMPACT VERSION

• Length (mm) 1405
• Width (mm) 715
• Height (mm) 1053
• Tank capacity (L) 50
• Net weight (kg) 387

DIMENSIONS SOUNDPROOFED VERSION M126

• Soundproofing type M126
• Length (mm) 1750
• Width (mm) 775
• Height (mm) 1230
• Tank capacity (L) 50
• Net weight (kg) 530
• Sound pressure level @1m in dB(A)
• 50Hz (75% PRP) 71
• Sound pressure level @7m in dB(A) 58

General

• Engine brand MITSUBISHI
• Ref. Engine S3L2-SD *
• Atmo Suction Type
• Diesel fuel
• Cylinder arrangement L
• Number of cylinders 3
• Displacement (l) 1,32
• Diameter (mm) * Stroke (mm) 78 * 92
• Compression ratio 22 : 1
• Speed (tr/mn) 1500
• Max. auxiliary power at nominal speed (kW) 11.20
• Frequency regulation (%) +/- 2.5%
• Type of injection Indirect
• Type of control Mechanical
• Air filter type, Dry models

Fuel system

• Maximum flow rate of fuel oil pump (l/h) 18
• Max. pressure in fuel circuit (m) 1.50
• Consumption with fan
• Consumption 110% load (l/h) 0
• Consumption 100% PRP load (l/h) 3.10
• Consumption 75% PRP load (l/h) 2.50
• Consumption 50% PRP load (l/h) 2.10

Lubrication system

• Oil capacity (l) 4,20
• Min. oil pressure (bar) 0.50
• Max. oil pressure (bar) 4
• Oil sump capacity (l) 3,70
• Oil consumption 100% ESP 50Hz (l/h) 0.02
• Air intake system
• Max. inlet back pressure (mm H2O) 200
• Combustion air flow rate (l/s) 13.60

Cooling system

• Engine and radiator capacity (l) 4.20
• Fan power (kW) 0.40
• Fan air flow rate (m3/s) 0.50
• Radiator back pressure (mm H2O) 10
• Type of cooling Glycol-Ethylene
• Radiated heat (kW) 1
• Heat expelled in the water HT (kW) 10
• Water temperature at outlet (°C) 93
• Engine stop water temperature (°C) 111
• Start of opening of HV thermostat (°C) 82
• Total opening of the HV thermostat (°C) 95

Alternator specifications

• KOHLER alternator trademark
• Ref. Alternator KH00350T
• Number of poles 4
• Number of bearings
• Ring and brushless technology
• IP23 protection rating
• Insulation class H
• Number of threads 12
• Ability to maintain a
• short circuit at 3 In for 10 s
• Yes
• AVR adjustment Yes
• Direct Coupling

Application data

• Excess speed (rpm) 2250
• Power factor (Cos Phi) 0.80
• Regulating the voltage to the regime
• established (+/- %) 1
• Waveform: NEMA=TIF <45
• Waveform: IEC=FHT <2
• Total harmonic distortion in
• vacuum DHT (%) 2.6
• Total harmonic distortion in
• DHT load (%) 2.3
• Response time (Delta U = 20%)
• transitional) (ms) 200
