Engine Lombardini Marine LDW 502 SD Expand

Marine Lombardini Engine LDW 502 SD

Lombardini Marine Lombardini Marine

LDW 502 SD

New

This Marine Lombardini LDW 502 SD engine has the great versatility and efficiency of the Sail Drive range. Highlighting the following features:

  • 2 Cylinders
  • Maximum power in KW 8
  • Maximum power in HP: 11
  • Water-cooled Engine
  • Stage: FOCS

More details

Caja Transporte Asvarta

Envío internacional gratuito*

Free shipping worldwide.
*See conditions

Distribuidores Oficiales Kohler y Lombardini

Kohler and Lombardini official distributors

LDW 502 SD Marine Lombardini

Absolute reliability in the development of your marine activities. Find the best versatility and maximum projection in the type of Engine you are looking for. Find the best compact grade possible thanks to the successful finish of the LDW 502 SD Marine engine from the Sail Drive range.

LDW 502 SD Sail Drive Marine Engine

Its finish has the following characteristics:

  • Unit injection pump in the casting
  • Vane lubrication pump
  • Self-priming seawater pump
  • Air Filter
  • Anti-corrosion surface treatment
  • One-piece aluminium cylinder head
Height108
FuelDiesel
RangeSail Drive
Max power (kW)8
Max power (kVA)11
  • Cylinders 2
  • Bore & Stroke 72x62
  • Displacement (cm3) 505
  • Power Max HP 11 hp
  • Power Max KW 8 kw
  • Compression ratio 22,3:1
  • Weight 108 kg *
  • Round/Minute 3600
