Motor Pump SDMO AQUALINE INTENS ST 3.60 C5 Kohler

Motor Pump ST 3.60 C5

Ideal for all types of low-loaded and clean water. Work in the most professional way thanks to the capabilities of the engine Honda GX160_C5 integrated. Its motor capacity allows to work with a maximum flow rate of 900 liters per minute equivalent to 54 cubic meters per hour.

The suction height rises to 8 meters and elevation to 26 meters. With automatic baiting.

Highlight:

• Automatic cebadura
• Offering accessories
• engine professional Honda GX160_C5
• Distribution:valves in the lead
• Start: launcher
• Displacement: 163 cubic centimeters
• STAGE V

This product has the new regulations on contaminants in Eupra, according to the range STAGE V (2016/1628 EU). Our SDMO water pumps allow a control of all professional properties that allow adequate control of the different materials to be performed.

AQUALINE INTENS ST 3.60 C5

engine Professional HONDA suitable and waterproof. With an ideal design that allows a sustained service life and provides impeccable results.

ST 3.60 C5 motor pump Accessories

The following accessories are included with the purchase of this group:

• Grid
• Clamps
• Fittings to be screwed
• Manual of use and maintenance

WATER PUMP SPECIFICATIONS

• Range: AQUALINE INTENS
• Type liquid: Clear water with little sediment pump
• Suction diameter (mm) 76
• Backflow diameter (mm) 76
• Outflow maximum (L/min) 900
• Outlflow maximum (m3/h) 54
• Lifting height (m) 26
• Suction height (m) 8
• Granulometry (mm) 8
• Automatic priming: Yes
• Fuel: Petrol
• Tank (L): 3.10
• 75% cons. (l/h) * 0.90
• 75% Autonomy (h) * 3.40
• Sound power level guaranteed LwA dB(A) 105
• Acoustic pressure level @1m in dB(A) 90
• Acoustic pressure level @7m in dB(A) 75

ENGINE SPECIFICATIONS

• Engine brand HONDA
• Engine ref. GX1600_C5
• Distribution O.H.V.
• Start Starter
• Oil shutdown Oui
• Displacement (cm3) 163
• Oil system capacity including filters (L) 0,60

DIMENSIONS AND WEIGHT

• Length (cm) 50.50
• Width (cm) 41.40
• Height (cm) 44.80
• Dry Weight (kg) 29

PACKAGING

• Packaging type Box
• Length (cm) 52
• Width (cm) 42.50
• Height (cm) 46.50
• Weight (kg) 32
• Pallet type 120/80
• Number of box by pallet 12
• Pallet height (cm) 153
• weight of the packaged Pallet (kg) 394
