Water Pump Aqualine Specialist Trash 3 C5 Kohler SDMO

Motobomba Trash 3 C5 Aqualine Specialist SDMO

The TR version that Aqualine Intens makes available is intended for use in uns dirty water. Thanks to its efficiency in external conditions it guarantees a use with excellent results making the most of the power of your engine professional KOHLER.

In addition, this range of SDMO water pumps complies with the new environmental regulations imposed by the European Union. (STAGE V 2016/1628 EU)

Advantages Aqualine Specialist Trash 3 C5

• Pump with sturdy body.
• Automatic cebadura.
• Easy access to the turbine thanks to its design.
• Accessories offered.
• engine KOHLER professional with air cooling.

Accessories included Trash 3 C5 KOHLER SDMO

The following add-ons are included with the purchase of your motor pump at no additional cost:

• A grid.
• Quick connections.
• Clamps.
• Manual of use and maintenance.

If you consult below we highlight a number of complementary products for your motor pump that you can purchase separately.

WATER PUMP SPECIFICATIONS

• Range AQUALINE SPECIALIST
• Type liquid Extremely heavily sedimented water pump
• Suction diameter [mm] 76
• Backflow diameter (mm) 76
• Outflow maximum (L/min) 1083,33
• Outlflow maximum (m3/h) 65
• Lifting height (m) 25
• Suction height (m) 8
• Granulometry (mm) 20
• Automatic priming Yes
• Fuel Diesel Fuel
• Tank (L) 4,30
• 75% cons. (l/h) * 1,40
• 75% Autonomy (h) * 3,10
• Sound power level guaranteed LwA dB(A) 110
• Acoustic pressure level @1m in dB(A) 95
• Acoustic pressure level @7m in dB(A) 81

ENGINE SPECIFICATIONS

• Engine brand KOHLER DIESEL
• Engine ref. KD350_C5
• Distribution Diesel O.H.V.
• Start Starter
• Oil shutdown Non
• Displacement (cm3) 349
• Oil system capacity including filters (L) 1,20

DIMENSIONS AND WEIGHT

• Length (cm) 71,50
• Width (cm) 57
• Height (cm) 59
• Dry Weight (kg) 67

PACKAGING

• Packaging type Box
• Length (cm) 73
• Width (cm) 58
• Height (cm) 59,50
• Weight (kg) 79
• Pallet type 120/80
• Number of box by pallet 4
• Pallet height (cm) 132
• weight of the packaged Pallet (kg) 326
